Multifunctional integrated circuits 97 SERIES

DN10 dual pump unloading subplate H97039

Technical data
Max. pressure 350 bar
P1 max. flow 80 lpm *
P2 max. flow 40 lpm * Dimensions in mm
Weight 8,3 Kg
Manifold material Steel
M1 / M2 ports 1/4” G
P2/ P2 ports 1/2” G
P1/ P1 / A / B ports 3/4” G
T port 1” G
* The sum of the two pumps must not exceed 100 lpm.

104

1
83 37
20 49 69 91
8
45
90
120

2 79
37 79 99 37 79
3
30 60 20
79 90 99
110

P
A B
T T

79

60

N° Description Q.ty
1 M8x12 for mounting 3
2 Cutoff valve 20-180 bar 1
3 Bosch Rexroth relief valve VMD1.040 * 2
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
