P. 300
H3906
Cetop 3 modular valves 39 SERIES
Cetop 3 modular relief valve on A / 30 lpm H3906
3
Dimensions in mm
$ %
7
Technical data
Max. pressure 250 bar
Max. flow 30 lpm *
Weight 0,6 Kg
Manifold material Aluminium
7
$ %
3
3 7 $ % N° Description Q.ty
1 Ø 5,5 through hole for mounting 4
2 OR 108 i. Ø 8,73 cross section 1,78 4
3 Bosch Rexroth relief valve VS-30 * depicted with 1
screw adjustment
* for complete technical information, click on the blue link or go to the components
3 7 $ % section at the end of the catalogue
300 General catalogue January 2025 edition
