P. 298
H3946
Cetop 3 modular valves 39 SERIES
Cetop 3 modular relief valve on A and B / 20 lpm H3946
1 2
P
Dimensions in mm
A B 45
3 T
39
Technical data
Max. pressure 250 bar
Max. flow 20 lpm *
Weight 0,55 Kg
Manifold material Aluminium
85
153
P T A B
T
22,50
A B
P1 T1 A1 B1 P
42,50
N° Description Q.ty
1 Bosch Rexroth relief 2
valve VSBN-08A
depicted depicted with
screw adjustment *
2 Ø 5,5 through hole for 4
mounting
3 OR 108 i. Ø 8,73 cross 4
section 1,78
* for complete technical information, click on the
blue link or go to the components section at the
end of the catalogue
298 General catalogue January 2025 edition
