Load sensing modular Cetop 3 subplates for parallel circuits 32 SERIES
Intermediate subplate with 2 way compensated flow regulator H3201
fixed flow rate from 1 to 10 lpm and 1 Cetop 3 station / side A-B ports

Dimensions in mm

Technical data
Max. pressure 210 bar 7
Weight 0,9 Kg
Manifold material Aluminium $ %
A / B ports 3/8” G
3

$ %

3 7

/6

7
3

$ * % *

N° Description Q.ty
1 OR 2050 i. Ø 12,42 cross section 1,78 (P-T) 2
2 OR 2043 i. Ø 10,82 cross section 1,78 (LS) 1
3 Ø 8,5 through hole for tie rod 3
4 2 way compensated flow regulator Bosch Rexroth 0T.F1.00.09-Z * 1
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
210 General catalogue September 2023 edition
