Multifunctional integrated circuits 97 SERIES
Management block for simultaneous feeds
with a variable displacement pump 1/2” G - Stand alone section H97133

5
6

7
4 12
8 11

15,50 26,50

30,50 3 9
99 229
2
61
39

12 13 11 99 8,50 30
124

Technical data 1/2" G R 1/4" G
LS IN
Inlet max. flow 100 lpm
Regulated 6 bar spring 50 lpm 50
max. flow 12 bar spring 80 lpm 13
LS IN / LS OUT ports 1/4” G
T port 3/8” G ON-OFF
P / R ports 1/2” G 13 PROP. 12
Man. material Aluminium Steel 14 15 16
Max. pressure 250 bar 350 bar
Weight 2,5 Kg 4,4 Kg

P T LS OUT
18 1/2" G 3/8" G 1/4" G

17
