Cetop 3 subplates 36 SERIES

H3619
Ordering code

H 3 6 1 9 A - _ _

Hydrover product Relief valve
adjustment pressure range *
0 = 5-50 bar
Product series 1 = 30-100 bar
36 series - Cetop 3 subplates 2 = 50-210 bar
3 = 100-350 bar

Product ID
Relief valve
adjustment type *
S = Screw
K = Knob

Manifold material
Aluminium

* Omit if not required. For example, to order the product without the relief cartridge valve, omit the pressure range and
adjustment type options: H3619A.
The manifold will still be provided with the corrisponding cavity.
To inhibit the relief valve, replace the related options with TL: H3619A-TL.
In the cavity it will be mounted a long plug.
Valve Cavity Long plug code
Pressure relief valve VS-30 008 D8TVMDC
