Cetop 3 valves 35 SERIES

Poppet type solenoid operated directional Cetop 3 valve P in A or P in B H3503

2

Dimensions in mm
1

49

46 77
143

Technical data
Max. pressure Aluminium 250 bar
Steel 350 bar
Max. flow 40 lpm *
Weight Aluminium 0,8 Kg
Steel 1,6 Kg
Manifold material Aluminium or steel 3 4

5

Closed A
P
23

A B

28 Closed T
P in B version depicted

N° Description Q.ty
1 Bosch Rexroth solenoid valve VEI-16-08A-NC OD.15-X-18-Y-000000 (normally closed) or VEI-16-08A-NA 1
OD.15-X-18-Y-000000 (normally open) depicted without manual override *
2 Connector DIN 43650 ISO 4400 1
3 Ø 5,5 through hole with counterbore for mounting 4
4 Bosch Rexroth coil D36 - CLASS H DIN 43650 ISO 4400 * 1
5 OR 108 i. Ø 8,73 cross section 1,78 4
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
