Load sensing modular Cetop 3 subplates for parallel circuits 32 SERIES

Closing plate with T port and relief valve H3208

Dimensions in mm

Technical data
Max. pressure 250 bar
Max. flow 90 lpm *
Weight 0,8 Kg
Manifold material Aluminium
T port 1/2” G

/6
7 *
7

3

N° Description Q.ty N° Description Q.ty
1 Ø 8,5 through hole for tie rod 3 5 Bosch Rexroth relief valve VSPN-10A * 1
2 OR 2050 i. Ø 12,42 cross section 1,78 (P-T) 2 depicted with screw adjustment
3 OR 2043 i. Ø 10,82 cross section 1,78 (LS) 1 6 M8x13 for mounting 2
4 OR 108 i. Ø 8,73 cross section 1,78 1

* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
