Load sensing modular Cetop 3 subplates for parallel circuits 32 SERIES
Intermediate subplate with 2 way compensated flow regulator / relief valve on P H3231
pilot operated check valves on A and B / 1 Cetop 3 station / side A-B ports
1
2
62 115
3 Dimensions in mm
14,50
24 129 59
154
Technical data
Max. pressure 250 bar T
Weight 2,6 Kg 24
Regulated max. flow 25 lpm A B
Manifold material Aluminium
A / B ports 3/8” G P
42
4
5 6 5 4
7
8
5
A B
P T
LS LS
P P
T T
A B
3/8" G 3/8" G
