Modular Cetop 3 subplates for parallel circuits 31 SERIES

Intermediate / closing subplate with 1 Cetop 3 station / back A-B ports H3105

Dimensions in mm

7

$ %

Technical data 3
Max. pressure 250 bar
Weight 0,6 Kg
Manifold material Aluminium
A / B ports 3/8” G

$ %
; ;

$ %
3 7

$ %

3
7
$ %
* *

N° Description Q.ty
1 OR 2062 i. Ø 15,60 cross section 1,78 (P-T) 2 $ % ; ;
2 Ø 11,5 through hole with 1/4” G thread (P-T) 2
3 Ø 8,5 through hole for tie rod 3

178 General catalogue September 2023 edition
