P. 108
Inline valves 17 SERIES
Inline permanent or switchable regenerative control valve 3/4” G H17009
Dimensions in mm
Technical data N° Description Q.ty
Max. pressure 350 bar 1 Ø 6,5 through hole for mounting 2
Max. flow pump 80 lpm
Max. flow regenerated oil About 150 lpm
Weight 4,1 Kg
Manifold material Steel
C1 / C2 / V1 / V2 ports 3/4” G
C1 C1
3/4" G 3/4" G
C1 V1 C1
3/4" G 3/4" G 3/4" G 1,5 V1
3/4" G
C2 V2 C2 V2
3/4" G 3/4" G 3/4" G 3/4" G
Permanent regeneration Switchable regeneration
108 General catalogue September 2023 edition
