Inline valves 17 SERIES

Inline permanent or switchable regenerative control valve 1/2” G H17095

Dimensions in mm

65
1

77
62 115 121

40

18 18

17,50 7,50 55 17,50
35 70

Technical data N° Description Q.ty
Max. pressure 250 bar 1 Ø 6,5 through hole for mounting 2
Max. flow pump 30 lpm
Max. flow regenerated oil About 90 lpm
Weight 0,9 Kg
Manifold material Aluminium
C1 / C2 / V1 / V2 ports 1/2” G

C1 C1
1/2"G V1 1/2"G V1
1/2"G 1/2"G

C2 V2 C2 V2
1/2"G 1/2"G 1/2"G 1/2"G

Permanent regeneration Switchable regeneration
