Inline valves 17 SERIES

Inline relief valve electrically enabled / A-B 3/8” G / 30 lpm H17086

40
20 39

20,50 Dimensions in mm

60 124 48

4

2 3 6

5

1

Technical data 15 36
Max. pressure 250 bar
Max. flow 30 lpm *
Weight 0,86 Kg
Manifold material Aluminium
P / T ports 3/8” G 20

Normally open
P
3/8"G

P T
3/8"G 3/8"G

Normally closed

P
3/8"G

P T
3/8"G 3/8"G

N° Description Q.ty
1 Bosch Rexroth coil D36 - CLASS H DIN 43650 ISO 4400 * 1
2 Connector DIN 43650 ISO 4400 1
Bosch Rexroth solenoid valve VEI-16 OD.15.05.18-Y-000000 (normally closed) o 1
3
VEI-16 OD.15.06.18-Y-000000 (normally open) depicted without manual override *
4 Ø 6,5 through hole for mounting 2
5 Bosch Rexroth relief valve VMD1.025 * 1
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
86 General catalogue September 2023 edition
