Modular Cetop 5 subplates for parallel circuits 51 SERIES
Inlet subplate with 1 station / extensible / relief and bypass valve H5101
side A-B ports / crossing P-T ports

1
8 83 5
3
4 Dimensions in mm
99 42 83

2
28,50 6
212 85 8 25,50 49,50 7
91,50 99

Technical data
Max. pressure 250 bar 9 117
Max. flow 150 lpm *
Weight 3,9 Kg T 8
Manifold material Aluminium A P
M port 1/4” G B
P / A / B ports 3/4” G T 49,50
T port 1” G 100

100

49,50

N° Description Q.ty
1 Connector DIN 43650 ISO 4400 1
2 Ø 11,5 through hole with 1/4” G thread (P) 1
3 Ø 15 through hole with 3/8” G thread (T) 1 M A B
4 Bosch Rexroth relief valve VSPN-10A* 1 1/4"G P T
P
depicted with screw adjustment 3/4"G
5 Bosch Rexroth solenoid valve 1
OD.15.06.89-Y-000000 depicted without
manual override *
T
6 Bosch Rexroth coil D36 - CLASS H DIN 2 1"G
43650 ISO 4400 *
7 M10x15 thread for mounting 4
B
8 Ø 8,5 through hole for mounting with 2 A 3/4"G
3/4"G
counterbore
* for complete technical information, click on the blue link or go to the
components section at the end of the catalogue
