Cetop 3 modular valves 39 SERIES

H3933
Ordering code

H 3 9 3 3 A - _ _ - _ _ - _ _ - _ _ _

Hydrover product Solenoid
valve
coil connection *
Product series 1 = DIN 43650
39 series - Cetop 3 ISO 4400
modular valves

Solenoid valve
Product ID coil voltage *
OB = 12V DC
OC = 24V DC
Manifold material OD = 48V DC
Aluminium OU = 110V RAC
AH = 230V RAC

Relief valve
adjustment type * Solenoid valve
Screw = S manual override *
E0 = Without
EP = Push (NA)
Relief valve EV = Screw (NC)
pressure range * EG = Push and twist (NA)
25-120 bar = 1
40-200 bar = 2
200-350 bar = 3 Solenoid valve spool type *
NA = Normally open
NC = Normally closed

* Omit if not required. For example, to order the product without the relief cartridge valve, omit the relief valve adjustment
type and pressure range options: H3933A-E0-OC1.
The manifold will still be provided with the corrisponding cavity.
To inhibit a function, replace the related valve options with TL: eg H3933A-TL-E0-OC1.
In the cavity it will be mounted a long plug.
Valve Cavity Long plug code
Solenoid valve VEI-16-8A OD.15.05.18-Y-000000 or VEI-16-8A CA-08A-2N 0489A2005600000
OD.15.06.18-Y-000000
Pressure relief valve VMD1.040 CA-10A-2N 0489A2008500000
