Cetop 3 modular valves 39 SERIES

H3998
Ordering code

H 3 9 9 8 A - _ _ - _ _ - _ _ _

Hydrover product Solenoid valve
coil connection *
1 = DIN 43650 ISO 4400
Product series
39 series - Cetop 3 modular valves
Solenoid valve
coil voltage *
Product ID OB = 12V DC
OC = 24V DC
OD = 48V DC
Manifold material OU = 110V RAC
Aluminium AH = 230V RAC

Solenoid valve spool type * Solenoid valve
Normally open = NA manual override *
Normally closed = NC E0 = Without
Normally open double lock = 2A EP = Push (NA, 2A)
Normally closed double lock = 2C EV = Screw (NC, 2C)
EG = Push and twist (NA, 2A)

* Omit if not required. For example, to order the product without coil, omit the solenoid valve coil connection and coil
voltage options: H3998A-NC-E0.

Normally open Normally closed
P T A B P T A B

P1 T1 A1 B1 P1 T1 A1 B1

Normally open double lock Normally closed double lock
P T A B P T A B

P1 T1 A1 B1 P1 T1 A1 B1
