Cetop 3 modular valves 39 SERIES

Cetop 3 modular proportional pressure reducing valve on B H3943

1
Dimensions in mm

44

100 2
3
196 26

T
22,50

45 A B Technical data
Max. pressure 250 bar
P Max. flow 45 lpm *
30 Weight 1,6 Kg

Manifold material Aluminium

79

4 5 P T A B

P

A B
M
T 1/4" G
P1 T1 A1 B1

N° Description Q.ty
1 Bosch Rexroth proportional solenoid valve VEP-5A-2R-06-P / OD.91.06.77-Y-00 * 1
2 Bosch Rexroth coil S5-356 - CLASS H DIN 43650 ISO 4400 * 1
3 Connector DIN 43650 ISO 4400 1
4 Ø 5,5 through hole for mounting 4
5 OR 108 i. Ø 8,73 cross section 1,78 4
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
