Inline valves 17 SERIES

Flow regulator 3 way compensated inline valve with bypass and relief H17045

1 2
Dimensions in mm

52
26
66 3
110 4
175

5

6
7

116 140 179
85,50

65

26 8 94 26

Technical data 77
Max. pressure 250 bar
Input max. flow (E) 200 lpm
Ouput regulated 150 lpm 34
max. flow (C)
Weight 3,1 Kg
Manifold material Alumi-
nium
M port 1/4” G
C / E / T ports 3/4” G

N° Description Q.ty
1 Bosch Rexroth relief valve VSBN-08A * 1
2 Connector DIN 43650 ISO 4400 1
Bosch Rexroth solenoid valve VEI-16-08A-NC OD.15.05.18-Y-000000 (normally closed) o VEI-16-08A-NA 1
3
OD.15.06.18-Y-000000 (normally open) depicted without manual override *
4 Bosch Rexroth coil D36 - CLASS H DIN 43650 ISO 4400 * 1
5 Restrictor Bosch Rexroth 1
6 Ø 8,5 through hole for mounting 2
7 Compensator Bosch Rexroth 1
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
