Inline valves 17 SERIES
Inline valve with poppet type solenoid operated directional valve H17111
Opposite 3/4” G ports / 70 lpm
Dimensions in mm
3
4
2
1
79 65
20 20
7
22,50 39,50 30 22,50
45 79
N° Description Q.ty
Bosch Rexroth solenoid valve VEI-16-12G-NC OD.15-X-17-Y-000000 (normally closed) or
1 1
VEI-16-12G-NA OD.15-X-17-Y-000000 (normally open) depicted without manual override *
2 Bosch Rexroth coil D36 - CLASS H DIN 43650 ISO 4400 * 2
3 Connector DIN 43650 ISO 4400 1
4 Ø 8,5 through hole for mounting 1
* for complete technical information, click on the blue link or go to the components section at the end of the catalogue
Technical data
Max. flow 70 lpm *
Ports 3/4” G
Manifold material Aluminium Steel
Max. pressure 250 bar 350 bar
Weight 1,05 Kg 2,1 Kg
