Inline valves 17 SERIES
Inline pump bypass / 150 lpm H17028
4
Dimensions in mm
79
1
2
3
120
59 227
Technical data
Max. pressure 350 bar
Max. flow 150 lpm
Weight 4 Kg
Manifold material Steel 31,50
P1 port 1/2” G 17,50
52
P / P2 / T ports 3/4” G 98
9,50
43
50 25
N° Description Q.ty
Directional valve normally 1
1
closed 20-180 bar 19,50
2 Hydrover logic element 1 42,50
Ø 8,5 through hole for 2
3
mounting
4 Bosch Rexroth check valve 1
75
103
T P
3/4" G 3/4" G
P2 P1
3/4" G 1/2" G
Low pressure High pressure
